TECHNICAL SPECIFICATIONS:
Display:
• LCD 16×2
Power Supplies:
• DC Supply IC Regulated +12V, +5V DC, 150mA.
• Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
• 89C51 Microcontroller
• Relay
• Buzzer
• Water Jar 2 Litre with Capacitive Sensor 3Nos.
SALIENT FEATURES:
• Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
• Fuse for Short Circuit protection
• Instruction manual.
• Connections are brought out through 10Pin FRC Male
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 12”x 8”
OPTIONAL ACCESSORIES:
• Multimeter
• Digital Thermometer
PIL-E454 WATER LEVEL MEASUREMENT USING CAPACITIVE TRANSDUCER TRAINER
In Stock
Water Level Measurement Using Capacitive Transducer Trainer is an SSI India product in the Electronics category. Key specifications include SKU: PIL-E454. DC Supply IC Regulated +12V, +5V DC, 150mA. Operated on Mains power 230V, 50Hz +10% Components are mounted on the panels are. Water Jar 2 Litre with Capacitive Sensor 3Nos. Connections are brought out through 10Pin FRC Male. Size of the trainer set 12”x 8” OPTIONAL ACCESSORIES.
