The various sensors covered are :
Specification
Thermal / Temperature Sensors with heater: RTD
Strain Sensors (For Pressure): Pressure measurement by Strain Gauges Load Cell mounted on cantilever beam with weights
Displacement (Linear / Angular): Linear – LVDT mounted on Base with Centre Zero Micrometer
Linear – Displacement measurement by LDR
Angular – Speed measurement by Optical Transducer
Angular – Displacement measurement by Rotary Potentiometer
Special Purpose Sensor: Anemometer (For Speed measurement of AIR)
Sound Sensor: Speaker and Microphone as Sound Transducer
Digital Meters: Digital Meters are provided on Board For (Temperature, Distance and Speed Measurement)
Electrical Kettle: Electrical Kettle is provided with Thermometer
Weight Box: Weight Box with different Weights will be provided for Weight Measurement.
Power On: Power ON switch with indicator for mains on indicator And fuse for protection
Power Requirement: 230V +/- 10% 1 phase AC
SIZE & WEIGHT (approx.): 255 mm (L) x 330 mm (W) x100mm (H), 1.5 Kg.
Accessories: Set of 12 stackable patch cords & Detailed Instruction
Manual
