TECHNICAL SPECIFICATIONS
Digital Meters:
• Voltmeter 20VDC
• Ammeter 200mA DC
Power supplies:
• DC Supply IC Regulated 0-6V DC, 150mA.
• Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
• Fuse for Short Circuit protection
Components are mounted on the panels are:
• Thermistor 10K.
• Heating Oven On Board Controlled By ON/OFF Switch.
• Voltage Control through Potentiometer.
• 110 Degree Thermometer
SALIENT FEATURES:
• Instruction manual.
• Operated on Mains power 230V, 50Hz.
• Patch Cords 4mm.
• Supply provided through the 3 pin computer socket with appropriate fuse
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 12”x8”
• Voltmeter 20VDC
PBE-E074 THERMISTOR CHARACTERISTICS TRAINER
In Stock
Thermistor Characteristics Trainer is an SSI India product in the BASIC ELECTRONICS LAB category. Key specifications include SKU: PBE-E074. Ammeter 200mA DC Power supplies. DC Supply IC Regulated 0-6V DC, 150mA. Voltage Control through Potentiometer. 110 Degree Thermometer SALIENT FEATURES. Operated on Mains power 230V, 50Hz. Supply provided through the 3 pin computer socket with appropriate fuse. Size of the trainer set 12”x8”.
