TECHNICAL SPECIFICATIONS
Digital Meters:
• Voltmeter 20V DC.
• Ammeter 200mA DC.
• Voltmeter 200V DC.
Power Supplies:
• DC Supply IC Regulated 0-5V DC, 150mA.
• DC Supply IC Regulated 0-30V DC, 150mA.
• Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
• Power Transistor 2N3055
• Voltage Control through Potentiometer.
SALIENT FEATURES:
• Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
• Fuse for Short Circuit protection
• Instruction manual.
• Connections are brought out through 4mm Colored Sockets.
• Patch Cords 4mm.
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 12”x8”
OPTIONAL ACCESSORIES:
• Multimeter
PBE-E068 POWER TRANSISTOR CHARACTERISTICS (DIGITAL METERS)
In Stock
Power Transistor Characteristics Digital Meters is an SSI India product in the BASIC ELECTRONICS LAB category. Key specifications include SKU: PBE-E068. DC Supply IC Regulated 0-5V DC, 150mA. DC Supply IC Regulated 0-30V DC, 150mA. Operated on Mains power 230V, 50Hz +10% Components are mounted on the panels are. Voltage Control through Potentiometer. Connections are brought out through 4mm Colored Sockets. Size of the trainer set 12”x8” OPTIONAL ACCESSORIES.
