TECHNICAL SPECIFICATIONS
Analog Meters:
• Voltmeter 20VDC.
• Ammeter 200mA DC.
• Voltmeter 200V DC.
Power Supplies:
• DC Supply IC Regulated 0-6V DC, 150mA.
• DC Supply IC Regulated 0-30V DC, 150mA.
• Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
IGBT 25N120
Voltage Control through Potentiometer.
SALIENT FEATURES:
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Fuse for Short Circuit protection
Instruction manual.
Connections are brought out through 4mm Colored Sockets.
Patch Cords 4mm.
The trainer is housed in ABS Plastic cabinet.
Size of the trainer set 12”x 8”
OPTIONAL ACCESSORIES:
Multimeter
