TECHNICAL SPECIFICATIONS
Meters:
Voltmeter 300V
Ammeter 5A
Galvanometer
Power supplies:
Power Supply 0-6V, 20A.
Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
Standard CT 20/1, 15/1, 5/1
Test CT 20/1, 15/1, 10/1, 5/1
Shunt Resistor 1E/5A, 0.5E/10A, 0.35E/15A, 0.25E/20A
Auto Transformer 2A Single Phase
Mutual Inductor
4 Wire Potentiometer
SALIENT FEATURES:
Light Indicator for Mains.
Front panel built with high class insulated Printed Bakelite/Aluminum Board sheet with well printed circuits and symbols.
MCB for Short Circuit protection
Instruction manual.
Connections are brought out through 4mm Colored Safety Sockets.
Patch Cords 4mm.
The trainer is housed in Metal cabinet.
Size of the trainer set 36×24”
OPTIONAL ACCESSORIES:
NO
