TECHNICAL SPECIFICATIONS
Power Supplies:
AC Power Supply 0-230V AT 4A (Optional)
Operated on Mains power 230V, 50Hz +10%
Digital/Analog Meters:
Voltmeter 2 Nos.
Ammeter 2Nos.
Over Current Relay (For Overload Protection)
4A Variac.
Transmission Lines 400Km (Through Resistor-Capacitor and Inductors)
Components are mounted on the panels are:
Single Phase Lamp Load Switch Control
SALIENT FEATURES:
Front panel built with high class insulated Bakelite sheet with Sticker well printed circuits and symbols.
Instruction manual.
Patch Cords 4mm (Heavy Duty) 1Meter Length.
High Voltage Test Points are Provided With 4mm Safety Sockets
The trainer is housed in Metal cabinet.
Short Circuit protection with the MCB.
Size of the trainer set 36”x24”
OPTIONAL ACCESSORIES:
Wattmeter (Digital)
