TECHNICAL SPECIFICATIONS:
Compact Microwave Lab kit consists of the following Components and Instruments:-
S. No. COMPONENT & INSTRUMENTS QTY. (NOS)
1 Klystron Mount 1
2 Klystron Tube 1
3 Isolator 1
4 Frequency Meter 1
5 Variable Attenuator 1
6 Detector Mount 1
7 Radiation Pattern set with tripod stand 1
8 Standard Gain Horn 1
9 Coaxial to WG Adopter 1
10 Waveguide stand 4
11 VSWR Meter 1
12 Klystron Power Supply 1
13 Cooling Fan with stand 1
14 BNC Cable 2
15 Waveguide Twist 1
16 Pick up horn 1
17 Slotted Antenna – Broad Wall 1
18 Slotted Antenna – Narrow Wall 1
19 Dielectric Antenna 1
20 E-Sectoral Horn 1
21 H-Sectoral Horn 1
22 Bend 2
23 Circulator 1
24 Movable Short 1
25 Parabolic Disc (with feed) 8″ dia 1
26 Pyramidal Horn
