TECHNICAL SPECIFICATIONS:
Power Supplies:
• DC Dual Power Supply IC Regulated +12V DC, 150mA.
• DC Power Supply IC Regulated +5V DC, 150mA.
• DC Power Supply IC Regulated 0-12V DC, 150mA.
• Operated on Mains power 230V, 50Hz +10%
Digital Meters:
• Voltmeter 200mV (Distance in mV)
Components are mounted on the panels are:
• Resistors
• Capacitors
• IC 741
• Variable Resistor For Gain and Zero Setting
• Differential Amplifier With Feedback
• Lead Compensation System
• O/P Provided On Test Points for Monitoring & Controlling.
• Photo Transistor Sensor Mounted on External Base with Output Carrying out through 2mm Connector.
SALIENT FEATURES:
• Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
• Instruction manual.
• Connections are brought out through 2mm Colored Sockets.
• Patch Cords 2mm.
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 12”x 8”
OPTIONAL ACCESSORIES:
• Digital Multimeter
PIL-E304A PHOTO TRANSISTOR AS MEASUREMENT TRANSDUCER TRAINER
In Stock
Photo Transistor As Measurement Transducer Trainer is an SSI India product in the Electronics category. Key specifications include SKU: PIL-E304A. TECHNICAL SPECIFICATIONS: Power Supplies. DC Dual Power Supply IC Regulated +12V DC, 150mA. DC Power Supply IC Regulated +5V DC, 150mA. DC Power Supply IC Regulated 0-12V DC, 150mA. Operated on Mains power 230V, 50Hz +10% Digital Meters. Voltmeter 200mV (Distance in mV) Components are mounted on the panels are.
