TECHNICAL SPECIFICATIONS:
Digital Meters:
• Voltmeter 200mV/2V DC.
Power Supplies:
• DC Supply IC Regulated +12V DC, 150mA.
• Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
• Thermocouple
• RTD (PT100)
• Thermistor NTC
• Variable Resistor
• 741 IC
• Electrical Kettle as Heating Element.
• Thermometer
SALIENT FEATURES:
• Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
• Fuse for Short Circuit protection
• Instruction manual.
• Connections are brought out through 2mm Colored Sockets.
• Patch Cords 2mm.
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 12”x8”
OPTIONAL ACCESSORIES:
• Multimeter
• Digital Thermometer
PIL-E151 TEMPERATURE TRANSDUCER TRAINER
In Stock
Temperature Transducer Trainer is an SSI India product in the Electronics category. Key specifications include SKU: PIL-E151. DC Supply IC Regulated +12V DC, 150mA. Operated on Mains power 230V, 50Hz +10% Components are mounted on the panels are. Thermometer SALIENT FEATURES. Connections are brought out through 2mm Colored Sockets. Size of the trainer set 12”x8” OPTIONAL ACCESSORIES. TECHNICAL SPECIFICATIONS: Digital Meters. Electrical Kettle as Heating Element.
