TECHNICAL SPECIFICATIONS:
• In built IC based Fixed DC Regulated Power Supply +12VDC/100mA.
• On board 1KHz sine wave oscillator provided.
• Input amplifier stage using TL074.
• Optical transmitter
• Optical Receiver
• Low Pass filter given on board.
• AC amplifier given on board.
• Power Amplifier given on board with volume control.
• Circuit diagram is printed on glass epoxy PCB & different combination of resistance.
• Test points are brought out on front panel.
SALIENT FEATURES:
• 660nm Transmitter.
• Photo Detector.
• On-board Sine wave generator:10Hz
• On-board 4th Order Low Pass Filer
• Two PMMA Optical Fiber Cables 1mtr and 3mtr Length.
• In-Built DC Regulated Power Supply.
• Front Panel Built With High Class Insulated Printed Circuit Board Sheet With Well Printed Circuits and Symbols.
• Fuse For Short Circuit Protection
• Instruction Manual.
• Connections are brought out through 2mm Brass Sockets.
• Patch Cords 2mm.
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 12”x 8”
OPTIONAL ACCESSORIES:
• CRO
• OPTICAL POWER METER
PFO-E160A ANALOG FIBER OPTIC TRAINER
In Stock
Analog Fiber Optic Trainer is an SSI India product in the FIBER OPTICS TRAINER KITS category. Key specifications include SKU: PFO-E160A. In built IC based Fixed DC Regulated Power Supply +12VDC/100mA. On board 1KHz sine wave oscillator provided. Input amplifier stage using TL074. Power Amplifier given on board with volume control. On-board Sine wave generator:10Hz. On-board 4th Order Low Pass Filer. Two PMMA Optical Fiber Cables 1mtr and 3mtr Length.
