TECHNICAL SPECIFICATIONS:
Power Supplies:
DC Power Supply 0-230V AT 2A (Field)
Operated on Mains power 230V, 50Hz +10%
Digital/Analog Meters:
Voltmeter
Ammeter
Components are mounted on the panels are:
Variac 2A (1Phase)
DC Starter (3 Point)
Lamp Load (Switched Control)
Emergency Stop Switch.
SALIENT FEATURES:
Front panel built with high class insulated Bakelite sheet with Sticker well printed circuits and symbols.
The trainer is housed in Modular Based Rack Type Aluminum Extruded Metal cabinet.
Instruction manual.
Patch Cords 4mm (Heavy Duty)
High Voltage Test Points are Provided With 4mm Safety Sockets
The trainer is housed in Metal cabinet.
Protection with Emergency Stop.
Short Circuit protection with the MCB.
Size of the trainer set 36”x24”
MOTOR SPECIFICATIONS:
DC Motor 2HP, 230V and DC Series Generator (1KW).
