TECHNICAL SPECIFICATIONS:
Power Supplies:
Power Supply +15Vat 150mA
Isolated Supply 0-220V AT 2A.
Operated on Mains power 230V, 50Hz +10%
Digital Meters:
Voltmeter 2000V AC
Ammeter 2A AC
Voltmeter 2000V DC
Ammeter 2A DC
Components are mounted on the panels are:
SCR TYN604
TRIAC BT136
LAMP LOAD
AC Phase Control by Gate Control Firing Circuit.
AC Phase Control by Triac Control Firing Circuit.
Snubbed Circuit.
SALIENT FEATURES:
10:1 Potential Divider for CRO
0.5 HP Universal Motor As Inductive Load
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Instruction manual.
Patch Cords 2mm and 4mm Both.
High Voltage Test Points are Provided With 4mm Safety Sockets
The trainer is housed in Metal cabinet.
Size of the trainer set 24”x20”
OPTIONAL ACCESSORIES:
CRO
