SPECIFICATIONS
Digital Meter:
Ammeter 20A DC Internally Connected Against Load.
Power supplies:
Isolated AC Power Supply 0-18, 3A
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Fuse for Short Circuit protection
Components are mounted on the panels are:
SCR TYN604
Load (12V Battery)
Variable Resistor 500E,1W
Diodes, Capacitors, Zener and Resistors
Salient Features:
Instruction manual.
Operated on Mains power 230V, 50Hz.
Patch Cords 4mm.
Supply provided through the 3 pin computer socket with appropriate fuse
The trainer is housed in ABS Plastic cabinet.
Size of the trainer set 12”x8”
