SPECIFICATIONS
Power supplies:
Isolated AC Power Supply: 12-0-12V, 250mA
Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
Fuse for Short Circuit protection
Components are mounted on the panels are:
SCR TYN604
2 Bit SCR Assembly
Load Through Rotary Switch
Firing Techniques:
R Firing
RC Firing
UJT Firing
Salient Features:
Instruction manual.
Operated on Mains power 230V, 50Hz.
Patch Cords 2mm.
Supply provided through the 3 pin computer socket with appropriate fuse
The trainer is housed in ABS Plastic cabinet.
Size of the trainer set 12”x 10”
Optional Accessories:
CRO
