TECHNICAL SPECIFICATIONS
Digital Meters:
• Voltmeter 10V DC.
• Ammeter 10Ma/100uA DC.
Power supplies:
• DC Supply IC Regulated 0-10V DC, 150mA.
• Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
• Voltage Control through Potentiometer.
ACCESSORIES INBUILT:
• LDR mounted on Separate unit.
• Light Source is housed in suitable box
• 100W Bulb as Light Source.
• Color Filters: Red, Yellow, Green, Blue and Violet.
• Stand to hold color filter.
• Wooden Optical Bench
SALIENT FEATURES:
• Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
• Fuse for Short Circuit protection
• Instruction manual.
• Connections are brought out through 4mm Colored Sockets.
• Patch Cords 4mm.
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 10”x8”
OPTIONAL ACCESSORIES:
• Multimeter
• Lux Meter
PBE-E098B SPECTRAL CHARACTERISTICS OF LDR
In Stock
Spectral Characteristics Of Ldr is an SSI India product in the BASIC ELECTRONICS LAB category. Key specifications include SKU: PBE-E098B. DC Supply IC Regulated 0-10V DC, 150mA. Operated on Mains power 230V, 50Hz +10% Components are mounted on the panels are. Voltage Control through Potentiometer. 100W Bulb as Light Source. Wooden Optical Bench SALIENT FEATURES. Connections are brought out through 4mm Colored Sockets. Size of the trainer set 10”x8” OPTIONAL ACCESSORIES.
