TECHNICAL SPECIFICATIONS
Analog Meters:
1. Voltmeter 30V
2. Ammeter 250mA
Power Supplies:
• 12-0-12 AC Isolated Power Supply.
• Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
• LM7812
• LM7912
• Load Resistor using Band switch
• Variable Resistor
SALIENT FEATURES:
• Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
• Fuse for Short Circuit protection
• Instruction manual.
• Connections are brought out through 4mm Colored Sockets.
• Patch Cords 4mm.
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 12”x8”
OPTIONAL ACCESSORIES:
• Multimeter
PBE-E025D FIXED VOLTAGE REGULATOR TRAINER
In Stock
Fixed Voltage Regulator Trainer is an SSI India product in the BASIC ELECTRONICS LAB category. Key specifications include SKU: PBE-E025D. TECHNICAL SPECIFICATIONS Analog Meters: 1. Ammeter 250mA Power Supplies. 12-0-12 AC Isolated Power Supply. Operated on Mains power 230V, 50Hz +10% Components are mounted on the panels are. Variable Resistor SALIENT FEATURES. Connections are brought out through 4mm Colored Sockets. Size of the trainer set 12”x8” OPTIONAL ACCESSORIES.
